Modelo | Caudal Nominal m³/h | Altura Recomendada m | Unidad Exterior 230Vx1 | Unidad Exterior 400Vx3 | Conexiones bomba de calor |
---|---|---|---|---|---|
RUND ECG 1000 DX10-LG | 2190 | 3-4,2 | UUD1 U30 (36) | UUD3 U30 (36) | 5/8" - 3/8" |
RUND ECG 1500 DX15-LG | 2920 | 3-4,2 | UUD1 U30 (48) | UUD3 U30 (48) | 5/8" - 3/8" |
RUND ECG 2000 DX22-LG | 4380 | 3-4,2 | - | UU70W U34 | 1" - 3/8" |
RUND ECG 2500 DX22-LG | 5110 | 3-4,2 | - | UU70W U34 | 1" - 3/8" |
RUND ECG 2500 DX27-LG | 5110 | 3-4,2 | - | UU85W U74 | 7/8" - 1/2" |
RUND ECG 3000 DX27-LG | 5840 | 3-4,2 | - | UU85W U74 | 7/8" - 1/2" |
Modelo | Caudal Nominal m³/h | Altura Recomendada m | Conexiones bomba de calor |
---|---|---|---|
RUND ECG 2000 VRF20-LG | 4380 | 3-4,2 | 1 |
RUND ECG 1000 VRF10-LG | 2190 | 3-4,2 | 5/8" - 3/8" |
RUND ECG 1500 VRF15-LG | 2920 | 3-4,2 | 5/8" - 3/8" |
RUND ECG 2000 VRF24-LG | 4380 | 3-4,2 | 1" - 3/8" |
RUND ECG 2500 VRF25-LG | 5110 | 3-4,2 | 7/8" - 1/2" |
RUND ECG 2500 VRF29-LG | 5110 | 3-4,2 | 7/8" - 1/2" |
RUND ECG 3000 VRF29-LG | 5840 | 3-4,2 | 7/8" - 1/2" |
RUND ECG 3000 VRF34-LG | 5840 | 3-4,2 | 7/8" - 1/2" |
Modelo | Caudal Nominal m³/h | Altura Recomendada m | Unidad Exterior 230Vx1 | Unidad Exterior 400Vx3 | Conexiones bomba de calor |
---|---|---|---|---|---|
RUND ECG 1000 DX10-LG | 2190 | 3-4,2 | UUD1 U30 (36) | UUD3 U30 (36) | 5/8" - 3/8" |
RUND ECG 1500 DX15-LG | 2920 | 3-4,2 | UUD1 U30 (48) | UUD3 U30 (48) | 5/8" - 3/8" |
RUND ECG 2000 DX22-LG | 4380 | 3-4,2 | - | UU70W U34 | 1" - 3/8" |
RUND ECG 2500 DX22-LG | 5110 | 3-4,2 | - | UU70W U34 | 1" - 3/8" |
RUND ECG 2500 DX27-LG | 5110 | 3-4,2 | - | UU85W U74 | 7/8" - 1/2" |
RUND ECG 3000 DX27-LG | 5840 | 3-4,2 | - | UU85W U74 | 7/8" - 1/2" |
Modelo | Caudal Nominal m³/h | Altura Recomendada m | Conexiones bomba de calor |
---|---|---|---|
RUND ECG 2000 VRF20-LG | 4380 | 3-4,2 | 1 |
RUND ECG 1000 VRF10-LG | 2190 | 3-4,2 | 5/8" - 3/8" |
RUND ECG 1500 VRF15-LG | 2920 | 3-4,2 | 5/8" - 3/8" |
RUND ECG 2000 VRF24-LG | 4380 | 3-4,2 | 1" - 3/8" |
RUND ECG 2500 VRF25-LG | 5110 | 3-4,2 | 7/8" - 1/2" |
RUND ECG 2500 VRF29-LG | 5110 | 3-4,2 | 7/8" - 1/2" |
RUND ECG 3000 VRF29-LG | 5840 | 3-4,2 | 7/8" - 1/2" |
RUND ECG 3000 VRF34-LG | 5840 | 3-4,2 | 7/8" - 1/2" |
