Air Curtain Invisair with Kleenfan Technology
Invisair air curtain, extremely discreet, to be installed in a way that is not visible, embedded in false ceilings and columns. Equipped with Kleenfan photocatalysis technology that disinfects and purifies the air, for commercial and industrial doors.
- Kleenfan technology with photocatalytic purificant action fans. UV-A rays, from the long-life led, act on the titanium dioxide of the turbine generation Reactive Oxygen Species (ROS) than, through oxidation /reduction reactions, inactivate wide range of pathogenic microorganisms (viruses and bacteria). It mineralizes most of the pollutants present in urban areas produced by vehicles and industry (NOx, SOx, COx, formaldehydes, VOCs, etc.).
- Specially designed for applications where the body of the air curtain is to be installed inside a column or bulkhead for architectural reasons. It can be vertically or horizontally mounted.
- Self-supporting casing construction made of galvanized steel plate, finished in structural epoxy-polyester painting white colour RAL9016 as standard. Other colours or stainless steel are available on request.
- The air flow of Invisair follows a straight line from the air inlet grille to the to the discharge. Inlet area inside a bulkhead or column should be designed with suitable grille provided by others.
- Anodized aluminium outlet vanes, airfoil shaped, adjustable from 0 to 15º each side.
- Low noise double-inlet centrifugal fans with external rotor motor. 5-speed controller. EC models assembled with very low consumption efficiency fans.
- “P” type with water heated coil. “E” type with electrical shielded elements, three stages with integrated regulation. “A” type without heating, air only. Optional expansion DX coil.
- Includes Plug&Play control with 7m RJ45 cable and infrared remote control. Optional: Clever control (programmable, automatic, intelligent, energy saving, Modbus RTU for BMS…)
Model Nominal Airflow
m³/hRecommended Installation Height
mIECG 1500 A FC 3600 3-4,2 IECG 2000 A FC 5400 3-4,2 IECG 2500 A FC 6300 3-4,2 Model Nominal Airflow
m³/hElectrical Heating Capacity 400Vx3
kWRecommended Installation Height
mIECG 1500 E FC 3600 7,5/15/22,5 3-4,2 IECG 2000 E FC 5400 10/20/30 3-4,2 IECG 2500 E FC 6300 10/20/30 3-4,2 Model Nominal Airflow
m³/hRecommended Installation Height
mHeating Capacity 80/60ºC (kW)
kWHeating Capacity 60/40ºC (kW)
kWHeating Capacity 50/40ºC
kWIECG 1500 P86 FC 3400 3-4,2 17.29 - - IECG 2000 P86 FC 5100 3-4,2 26.86 - - IECG 2500 P86 FC 5950 3-4,2 33.63 - - IECG 1500 P64 FC 3400 3-4,2 - 16.77 - IECG 2000 P64 FC 5100 3-4,2 - 24.14 - IECG 2500 P64 FC 5950 3-4,2 - 28.84 - IECG 1500 P54 FC 3400 3-4,2 - - 17.86 IECG 2000 P54 FC 5100 3-4,2 - - 25.24 IECG 2500 P54 FC 5950 3-4,2 - - 31.38 Model Nominal Airflow
m³/hRecommended Installation Height
mIECG 1500 A FC 3600 3-4,2 IECG 2000 A FC 5400 3-4,2 IECG 2500 A FC 6300 3-4,2 Model Nominal Airflow
m³/hElectrical Heating Capacity 400Vx3
kWRecommended Installation Height
mIECG 1500 E FC 3600 7,5/15/22,5 3-4,2 IECG 2000 E FC 5400 10/20/30 3-4,2 IECG 2500 E FC 6300 10/20/30 3-4,2 Model Nominal Airflow
m³/hRecommended Installation Height
mHeating Capacity 80/60ºC (kW)
kWHeating Capacity 60/40ºC (kW)
kWHeating Capacity 50/40ºC
kWIECG 1500 P86 FC 3400 3-4,2 17.29 - - IECG 2000 P86 FC 5100 3-4,2 26.86 - - IECG 2500 P86 FC 5950 3-4,2 33.63 - - IECG 1500 P64 FC 3400 3-4,2 - 16.77 - IECG 2000 P64 FC 5100 3-4,2 - 24.14 - IECG 2500 P64 FC 5950 3-4,2 - 28.84 - IECG 1500 P54 FC 3400 3-4,2 - - 17.86 IECG 2000 P54 FC 5100 3-4,2 - - 25.24 IECG 2500 P54 FC 5950 3-4,2 - - 31.38
